上海閥盛閥門制(zhi)造(zao)有限公司主要(yao)生產低(di)(di)功(gong)(gong)(gong)(gong)率(lv)(lv)氣液(ye)電(dian)(dian)磁(ci)(ci)閥，可(ke)提(ti)供低(di)(di)功(gong)(gong)(gong)(gong)率(lv)(lv)氣液(ye)電(dian)(dian)磁(ci)(ci)閥價格，低(di)(di)功(gong)(gong)(gong)(gong)率(lv)(lv)氣液(ye)電(dian)(dian)磁(ci)(ci)閥說明書，低(di)(di)功(gong)(gong)(gong)(gong)率(lv)(lv)氣液(ye)電(dian)(dian)磁(ci)(ci)閥實物(wu)圖，低(di)(di)功(gong)(gong)(gong)(gong)率(lv)(lv)氣液(ye)電(dian)(dian)磁(ci)(ci)閥結構圖，低(di)(di)功(gong)(gong)(gong)(gong)率(lv)(lv)氣液(ye)電(dian)(dian)磁(ci)(ci)閥外形尺寸(cun)，低(di)(di)功(gong)(gong)(gong)(gong)率(lv)(lv)氣液(ye)電(dian)(dian)磁(ci)(ci)閥執行標準，低(di)(di)功(gong)(gong)(gong)(gong)率(lv)(lv)氣液(ye)電(dian)(dian)磁(ci)(ci)閥工作原理，低(di)(di)功(gong)(gong)(gong)(gong)率(lv)(lv)氣液(ye)電(dian)(dian)磁(ci)(ci)閥作用特點。

低功率氣液電磁閥技術說明：

適用介質：水、氣、油

介質溫度：-10～80℃

動作方式：先導式

工作壓差：見下表（常閉）

閥體材料：黃銅（HPb59-1）

膜片密封，材料：丁腈橡膠

線圈保護等級：塑封線圈IP65

電壓波動范圍：AC -15%～10% DC -5%～10%

低功率氣液電磁閥主要技術參數 （注：介質溫度最高120℃時請選用氟橡膠膜片密封）： 產品型號 流量孔徑（mm） 螺紋G 工作壓差（bar） Cv值 A B （mm） （mm） RSQ-15 13.5 G3/8″ G1/2″ 0.5～16 4.5 66 82 RSQ-20 18 G3/4″ 0.5～12 5.8 79 89 RSQ-25 24 G1″ 0.5～12 14 105 106
